APPENDIX A
Message Comments
AHRS1 SRVC – AHRS1 Magnetic-field
model needs update. The #1 AHRS earth magnetic field model is out of date. Update magnetic field model
when practical.
AHRS2 SRVC – AHRS2 Magnetic-field
model needs update. The #2 AHRS earth magnetic field model is out of date. Update magnetic field model
when practical.
GEO LIMITS – AHRS1 too far North/
South, no magnetic compass.
The aircraft is outside geographical limits for approved AHRS operation. Heading is
flagged as invalid.
GEO LIMITS – AHRS2 too far North/
South, no magnetic compass.
MANIFEST – GRS1 software
mismatch, communication halted.
The #1 AHRS has incorrect software installed. The G1000 system should be serviced.
MANIFEST – GRS2 software
mismatch, communication halted.
The #2 AHRS has incorrect software installed. The G1000 system should be serviced.
GMU 44 MESSAGE ADVISORIES
Message Comments
HDG FAULT – AHRS1 magnetometer
fault has occurred. A fault has occurred in the #1 GMU 44. Heading is flagged as invalid. The AHRS uses
GPS for backup mode operation. The G1000 system should be serviced.
HDG FAULT – AHRS2 magnetometer
fault has occurred. A fault has occurred in the #2 GMU 44. Heading is flagged as invalid. The AHRS uses
GPS for backup mode operation. The G1000 system should be serviced.
MANIFEST – GMU1 software
mismatch, communication halted.
The GMU 44 has incorrect software installed. The G1000 system should be serviced.
MANIFEST – GMU2 software
mismatch, communication halted.
GDL 69A MESSAGE ADVISORIES
Message Comments
GDL69 CONFIG – GDL 69 config
error. Config service req’d. GDL 69 configuration settings do not match those of backup configuration memory.
The G1000 system should be serviced.
GDL69 FAIL – GDL 69 has failed. A failure has been detected in the GDL 69. The receiver is unavailable. The G1000
system should be serviced
MANIFEST – GDL software mismatch,
communication halted. The GDL 69 has incorrect software installed. The G1000 system should be serviced.
GWX 68 MESSAGE ADVISORIES
Message Comments
GWX CONFIG – GWX config error.
Config service req’d. GWX 68 configuration settings do not match those of the GDU configuration. The
G1000 system should be serviced.
GWX FAIL – GWX is inoperative. The GDU is not recieving status packet from the GWX 68 or the GWX 68 is reporting
a fault. The GWX 68 radar system should be serviced.
GWX SERVICE – GWX needs service.
Return unit for repair.
A failure has been detected in the GWX 68. The GWX 68 may still be usable.
MANIFEST – GWX software
mismatch, communication halted.
The GWX 68 has incorrect software installed. The G1000 system should be serviced.
