Hardware Schematic Diagram

After the SHL bit is configured, these settings normally are not changed.

•

Select the LCD bias settings.

♦

The duty cycle is selected as 1/65 by hardwiring the controller IC pads on the
display PCB.

♦

The LCD bias is set to:

1/7: when the BIAS bit is 0

1/9: when the BIAS bit is 1

The following steps are performed next:

•

Start the onboard converter, regulator, and follower

•

Set the regulator resistor values (see

Table C-4

)

•

Configure the reference voltage register parameters (see

Table C-5

)

At startup of the LCD controller (after RESETB operation), the resistor and reference
voltage values are:

•

Resistor selection is: 0,0,0

•

Reference voltage is: 1,0,0,0,0,0

The resistor selection value MUST be set to 101b when using this LCD panel.

After the display is brought to operational mode, it is best to wait at least 1 ms to ensure the
stabilization of power supply levels. After this time, all other necessary display
initializations can be performed.

Table C-4:

Resistor Value Settings

3-Bit Data Settings (R2 R1 R0)

000

001

010

011

100

101

110

111

1+(Rb/Ra)

1.90

2.19

2.55

3.02

3.61

4.35

5.29

6.48

Table C-5:

Reference Voltage Parameters

SV5

SV4

SV3

SV2

SV1

SV0

Reference Voltage Parameter (

α)

…
