Virtex-5 FPGA ML561 User Guide www.xilinx.com 117
UG199 (v1.2.1) June 15, 2009
R
Switch
DIP (Test Inputs) ITT_INDUSTRIES SDA04H1KD SW1, SW2, SW6
System Reset (Black) Panasonic EVQ11L07K SW4
Configuration Reset (Red) Panasonic EVQ11L05K SW7
Power Input (12V and 5V) APEM 25336NA SW3, SW5
Rotary 8-position Digikey GH3311-ND SW8
Capacitor
0402 (Assorted Values) Panasonic ECJ-xxx MLC_CAP_0402
0603 (Assorted Values) Panasonic ECJ-xxx MLC_CAP_0603
0805 (Assorted Values) Panasonic ECJ-xxx MLC_CAP_0805
Tantalum C Kemet T520xxx TANT_CAP_C
Tantalum D Kemet T520xxx TANT_CAP_D
Tantalum E Kemet T520xxx TANT_CAP_E
Inductor
DO3316 Coilcraft DO3316 Lxx
Ferrite Bead TDK MPZ1608S221A FBxx
0805 (assorted values) Digikey HZ0805E601R-00 Lxx
Resistor
0402 (assorted values) Panasonic ERJ-xxx Rxxx
0603 (assorted values) Panasonic ERJ-xxx Rxxx
0805 (assorted values) Panasonic ERJ-xxx Rxxx
Transistor MOSFET Diodes BSS138 Qxx
Table B-1: Bill of Materials (Continued)
Category Description Manufacturer Mfr. Part Number Reference Designators
