Xilinx Virtex-5 FPGA ML561 User Manual
Page 104
104
Virtex-5 FPGA ML561 User Guide
UG199 (v1.2.1) June 15, 2009
Appendix A: FPGA Pinouts
R
DDR2 DIMM Wide Interface (cont.)
DDR2_DIMM_DQ_BY15_B5
AD5
DDR2_DIMM_DQ_CB8_15_B4
N7
DDR2_DIMM_DQ_BY15_B6
AD4
DDR2_DIMM_DQ_CB8_15_B5
N8
DDR2_DIMM_DQ_BY15_B7
Y8
DDR2_DIMM_DQ_CB8_15_B6
M5
DDR2_DIMM_DQ_BY8_B0
G13
DDR2_DIMM_DQ_CB8_15_B7
M6
DDR2_DIMM_DQ_BY8_B1
F13
DDR2_DIMM_DQS_BY10_L_N
J9
DDR2_DIMM_DQ_BY8_B2
N9
DDR2_DIMM_DQS_BY10_L_P
J10
DDR2_DIMM_DQ_BY8_B3
N10
DDR2_DIMM_DQS_BY11_L_N
J7
DDR2_DIMM_DQ_BY8_B4
E13
DDR2_DIMM_DQS_BY11_L_P
H7
DDR2_DIMM_DQ_BY8_B5
E12
DDR2_DIMM_DQS_BY12_L_N
U7
DDR2_DIMM_DQ_BY8_B6
L9
DDR2_DIMM_DQS_BY12_L_P
T8
DDR2_DIMM_DQ_BY8_B7
M10
DDR2_DIMM_DQS_BY13_L_N
AF6
DDR2_DIMM_DQ_BY9_B0
A13
DDR2_DIMM_DQS_BY13_L_P
AE7
DDR2_DIMM_DQ_BY9_B1
H9
DDR2_DIMM_DQS_BY14_L_N
V7
DDR2_DIMM_DQ_BY9_B2
H10
DDR2_DIMM_DQS_BY14_L_P
W7
DDR2_DIMM_DQ_BY9_B3
C12
DDR2_DIMM_DQS_BY15_L_N
AF5
DDR2_DIMM_DQ_BY9_B4
D12
DDR2_DIMM_DQS_BY15_L_P
AG5
DDR2_DIMM_DQ_BY9_B5
J11
DDR2_DIMM_DQS_BY8_L_N
C13
DDR2_DIMM_DQ_BY9_B6
K11
DDR2_DIMM_DQS_BY8_L_P
B13
DDR2_DIMM_DQ_BY9_B7
D11
DDR2_DIMM_DQS_BY9_L_N
K9
DDR2_DIMM_DQ_CB8_15_B0 20
P5
DDR2_DIMM_DQS_BY9_L_P
K8
DDR2_DIMM_DQ_CB8_15_B1
N5
DDR2_DIMM_DQS_CB8_15_L_N
R8
DDR2_DIMM_DQ_CB8_15_B2
L6
DDR2_DIMM_DQS_CB8_15_L_P
R7
DDR2_DIMM_DQ_CB8_15_B3
M7
DDR2 DIMM Miscellaneous Signals
DDR2_DIMM1_CNTL_PAR
G27
DDR2_DIMM3_CNTL_PAR
AA28
DDR2_DIMM1_CNTL_PAR_ERR
H27
DDR2_DIMM3_CNTL_PAR_ERR
AG28
DDR2_DIMM1_NC_019
K24
DDR2_DIMM3_NC_019
AK29
DDR2_DIMM1_NC_102
L24
DDR2_DIMM3_NC_102
AJ29
DDR2_DIMM2_CNTL_PAR
AD26
DDR2_DIMM4_CNTL_PAR
AG8
DDR2_DIMM2_CNTL_PAR_ERR
AD25
DDR2_DIMM4_CNTL_PAR_ERR
AH8
DDR2_DIMM2_NC_019
AK28
DDR2_DIMM4_NC_019
AL10
DDR2_DIMM2_NC_102
AK27
DDR2_DIMM4_NC_102
AE8
Table A-2:
FPGA #2 Pinout (Continued)
Signal Name
Pin
Signal Name
Pin
