FPGA #3 Pinout
R
QDRII Memory Interface (cont.)
QDR2_Q_BY6_B7
V33
QDR2_Q_BY7_B4
W29
QDR2_Q_BY6_B8
V32
QDR2_Q_BY7_B5
Y31
QDR2_Q_BY7_B0
AB31
QDR2_Q_BY7_B6
W31
QDR2_Q_BY7_B1
Y29
QDR2_Q_BY7_B7
V27
QDR2_Q_BY7_B2
Y28
QDR2_Q_BY7_B8
V28
QDR2_Q_BY7_B3
V29
RLDRAM II Memory Interface
RLD2_A0
AD10
RLD2_CK_BY2_3_N
AE11
RLD2_A1
AD9
RLD2_CK_BY2_3_P
AF11
RLD2_A10
AC8
RLD2_CS_BY0_1_N
AK9
RLD2_A11
AP12
RLD2_CS_BY2_3_N
AK8
RLD2_A12
AA9
RLD2_DK_BY0_1_N
AH8
RLD2_A13
AA8
RLD2_DK_BY0_1_P
AG8
RLD2_A14
AM13
RLD2_DK_BY2_3_N
AH10
RLD2_A15
AN13
RLD2_DK_BY2_3_P
AH9
RLD2_A16
AA10
RLD2_QK_BY0_N
C13
RLD2_A17
AB10
RLD2_QK_BY0_P
B13
RLD2_A18
AP14
RLD2_QK_BY1_N
K9
RLD2_A19
AN14
RLD2_QK_BY1_P
K8
RLD2_A2
AE8
RLD2_QK_BY2_N
J7
RLD2_A3
AL10
RLD2_QK_BY2_P
H7
RLD2_A4
AL11
RLD2_QK_BY3_N
U7
RLD2_A5
AC9
RLD2_QK_BY3_P
T8
RLD2_A6
AC10
RLD2_QVLD_BY0_1
F11
RLD2_A7
AM11
RLD2_QVLD_BY2_3
U10
RLD2_A8
AM12
RLD2_REF_N
AJ9
RLD2_A9
AB8
RLD2_WE_N
AF9
RLD2_BA0
AJ11
RLD2_D_BY0_B0
D11
RLD2_BA1
AK11
RLD2_D_BY0_B1
H8
RLD2_BA2
AD11
RLD2_D_BY0_B2
G8
RLD2_CK_BY0_1_N
AG11
RLD2_D_BY0_B3
G10
RLD2_CK_BY0_1_P
AG10
RLD2_D_BY0_B4
F10
Table A-3:
FPGA #3 Pinout (Continued)
Signal Name
Pin
Signal Name
Pin
