FPGA #2 Test and Debug Signals
FPGA2_DIP0
AG18
FPGA2_SOFTTOUCH_BY1_B7
H17
FPGA2_DIP1
AG15
FPGA2_SPYHOLE_BK15
P29
FPGA2_DIP2
AH15
FPGA2_SPYHOLE_BK18
W9
FPGA2_DIP3
AG20
FPGA2_TEST_HDR_BY0_B0
AE23
FPGA2_SOFTTOUCH_BY0_B0
H20
FPGA2_TEST_HDR_BY0_B1
AE22
FPGA2_SOFTTOUCH_BY0_B1
H19
FPGA2_TEST_HDR_BY0_B2
AG12
FPGA2_SOFTTOUCH_BY0_B2
H13
FPGA2_TEST_HDR_BY0_B3
AF13
FPGA2_SOFTTOUCH_BY0_B3
J14
FPGA2_TEST_HDR_BY0_B4
AG23
FPGA2_SOFTTOUCH_BY0_B4
J21
FPGA2_TEST_HDR_BY0_B5
AF23
FPGA2_SOFTTOUCH_BY0_B5
J20
FPGA2_TEST_HDR_BY0_B6
AE12
FPGA2_SOFTTOUCH_BY0_B6
H15
FPGA2_TEST_HDR_BY0_B7
AE13
FPGA2_SOFTTOUCH_BY0_B7
H14
FPGA2_TEST_HDR_BY1_B0
K12
FPGA2_SOFTTOUCH_BY1_B0
J19
FPGA2_TEST_HDR_BY1_B1
K13
FPGA2_SOFTTOUCH_BY1_B1
K18
FPGA2_TEST_HDR_BY1_B2
H23
FPGA2_SOFTTOUCH_BY1_B2
G16
FPGA2_TEST_HDR_BY1_B3
G23
FPGA2_SOFTTOUCH_BY1_B3
G15
FPGA2_TEST_HDR_BY1_B4
H12
FPGA2_SOFTTOUCH_BY1_B4
L18
FPGA2_TEST_HDR_BY1_B5
J12
FPGA2_SOFTTOUCH_BY1_B5
K17
FPGA2_TEST_HDR_BY1_B6
K22
FPGA2_SOFTTOUCH_BY1_B6
H18
FPGA2_TEST_HDR_BY1_B7
K23
FPGA #2 Test Display Signals
FPGA2_7SEG_0_N
AG17
FPGA2_7SEG_6_N
AF19
FPGA2_7SEG_1_N
AH18
FPGA2_7SEG_DP_N
AG21
FPGA2_7SEG_2_N
AE18
FPGA2_LED0
AD19
FPGA2_7SEG_3_N
AF18
FPGA2_LED1
AE19
FPGA2_7SEG_4_N
AG16
FPGA2_LED2
AE17
FPGA2_7SEG_5_N
AH17
FPGA2_LED3
AF16
FPGA #2 External Interfaces
FPGA2_116_TX0_N
G2
FPGA2_120_RX1_P
D1
FPGA2_116_TX0_P
F2
FPGA2_124_TX0_N
B10
FPGA2_120_RX0_N
A2
FPGA2_124_TX0_P
B9
FPGA2_120_RX0_P
A3
FPGA2_124_TX1_N
B6
FPGA2_120_RX1_N
C1
FPGA2_124_TX1_P
B5
Table A-2:
FPGA #2 Pinout (Continued)
