Virtex-5 FPGA ML561 User Guide
101
UG199 (v1.2.1) June 15, 2009
FPGA #2 Pinout
R
DDR2 DIMM Deep Interface (cont.)
DDR2_DIMM3_CK2_P
AA25
DDR2_DIMM_DQ_BY0_B4
R27
DDR2_DIMM3_CKE0
AE28
DDR2_DIMM_DQ_BY0_B5
R26
DDR2_DIMM3_CKE1
AH28
DDR2_DIMM_DQ_BY0_B6
U28
DDR2_DIMM3_CS0_N
W25
DDR2_DIMM_DQ_BY0_B7
U27
DDR2_DIMM3_CS1_N
V25
DDR2_DIMM_DQ_BY1_B0
N29
DDR2_DIMM3_ODT0
AB26
DDR2_DIMM_DQ_BY1_B1
M30
DDR2_DIMM3_ODT1
AB25
DDR2_DIMM_DQ_BY1_B2
L30
DDR2_DIMM4_CK0_N
AK9
DDR2_DIMM_DQ_BY1_B3
J31
DDR2_DIMM4_CK0_P
AK8
DDR2_DIMM_DQ_BY1_B4
J30
DDR2_DIMM4_CK1_N
AJ11
DDR2_DIMM_DQ_BY1_B5
G31
DDR2_DIMM4_CK1_P
AK11
DDR2_DIMM_DQ_BY1_B6
H30
DDR2_DIMM4_CK2_N
AD11
DDR2_DIMM_DQ_BY1_B7
L29
DDR2_DIMM4_CK2_P
AD10
DDR2_DIMM_DQ_BY2_B0
E31
DDR2_DIMM4_CKE0
AG11
DDR2_DIMM_DQ_BY2_B1
F31
DDR2_DIMM4_CKE1
AG10
DDR2_DIMM_DQ_BY2_B2
J29
DDR2_DIMM4_CS0_N
W26
DDR2_DIMM_DQ_BY2_B3
H29
DDR2_DIMM4_CS1_N
Y26
DDR2_DIMM_DQ_BY2_B4
F30
DDR2_DIMM4_ODT0
AE11
DDR2_DIMM_DQ_BY2_B5
G30
DDR2_DIMM4_ODT1
AF11
DDR2_DIMM_DQ_BY2_B6
F29
DDR2_DIMM_DM_BY0
U30
DDR2_DIMM_DQ_BY2_B7
E29
DDR2_DIMM_DM_BY1
R31
DDR2_DIMM_DQ_BY3_B0
J32
DDR2_DIMM_DM_BY2
T31
DDR2_DIMM_DQ_BY3_B1
F34
DDR2_DIMM_DM_BY3
L33
DDR2_DIMM_DQ_BY3_B2
G33
DDR2_DIMM_DM_BY4
AK34
DDR2_DIMM_DQ_BY3_B3
E33
DDR2_DIMM_DM_BY5
AG32
DDR2_DIMM_DQ_BY3_B4
E32
DDR2_DIMM_DM_BY6
P34
DDR2_DIMM_DQ_BY3_B5
E34
DDR2_DIMM_DM_BY7
AK33
DDR2_DIMM_DQ_BY3_B6
F33
DDR2_DIMM_DM_CB0_7
M32
DDR2_DIMM_DQ_BY3_B7
G32
DDR2_DIMM_DQ_BY0_B0
T25
DDR2_DIMM_DQ_BY4_B0
Y34
DDR2_DIMM_DQ_BY0_B1
U25
DDR2_DIMM_DQ_BY4_B1
AA34
DDR2_DIMM_DQ_BY0_B2
T26
DDR2_DIMM_DQ_BY4_B2
AA33
DDR2_DIMM_DQ_BY0_B3
U26
DDR2_DIMM_DQ_BY4_B3
Y33
Table A-2:
FPGA #2 Pinout (Continued)
Signal Name
Pin
Signal Name
Pin
