Appendix B: Bill of Materials
R
Power
15A Power Module
Texas Instruments
VR1, VR6, VR9, VR10,
VR12, VR13
6A Power Module
Texas Instruments
VR2, VR4, VR14
4A LDO
Maxim
VR3, VR5, VR7, VR8
1.5A VLDO Regulator
Linear Technology
U15
DDR Bus Termination
Regulator
Fairchild
Semiconductor
U1, U2, U14, U42
Power Measurement Header
3M
P102
500 mA VLDO Regulator
Linear Technology
U16, U22
5A LDO
Texas Instruments
U23
Power Sensing Resistor
Isotek Corp.
R63, R724, R764, R777,
R874, R885, R954
Glue Logic
USB to RS-232 Bridge
Silicon Labs
U43
Schmitt Inverter
Toshiba
U32
Level Translator
Maxim
U10
RS-232 Compatible Transceiver
Maxim
U31
CMOS Octal Buffer
ON Semiconductor
U37, U38
Clock Buffer
LVCMOS, 1-to-4
Integrated Device
Technology
U19
LVCMOS, 1-to-4, 5V Tolerant
Integrated Device
Technology
U30, U44
Differential LVPECL, 1-to-6
Integrated Device
Technology
U17, U18
Diff. LVPECL-to-LVDS, 1-to-4
Integrated Device
Technology
U20
Diff. HCSL, 1-to-4
Integrated Device
Technology
U24
Display
7-Segment LED
Stanley Electric
D17, D23, D35
Socket/
Connector
Banana Jack (Red)
Hirschmann
J18, J25
Banana Jack (Black)
Hirschmann
J17, J24
RS232 DB-9 Port
Tyco Electronics
P73
USB Port
KYCON
J29
Test Headers (2x8)
Tyco Electronics
P20, P21, P93
CompactFlash Holder
Molex
J27
CompactFlash Ejector
Molex
5V Power Input Jack
CUI Inc.
J28
Power Fuse
Digikey
F1, F2
SMA for Ext Clock Inputs
AMPHENOL-RF
J16, J19, J20, J21
Table B-1:
Bill of Materials (Continued)
Category
Description
Manufacturer
Mfr. Part Number
Reference Designators
