ZyXEL Communications 662HW Series - Manual (Page 94)

Prestige 662H/HW Series User’s Guide
Chapter 8 Wireless LAN Setup 94
Click Wireless LAN, Wireless to open the Wireless screen.
Figure 26 Wireless LAN
The following table describes the fields in this screen.
Table 17 Wireless LAN
LABEL DESCRIPTION
Enable Wireless
LAN
The wireless LAN is turned off by default, before you enable the wireless LAN you
should configure some security by setting MAC filters and/or 802.1x security;
otherwise your wireless LAN will be vulnerable upon enabling it. Select the check
box to enable the wireless LAN.
ESSID The ESSID (Extended Service Set Identification) is a unique name to identify the
Prestige in the wireless LAN. Wireless stations associating to the Prestige must
have the same ESSID.
Enter a descriptive name (up to 32 characters).
Hide ESSID Select Yes to hide the ESSID in so a station cannot obtain the ESSID through
passive scanning.
Select No to make the ESSID visible so a station can obtain the ESSID through
passive scanning.
Channel ID The radio frequency used by IEEE 802.11b wireless devices is called a channel.
Select a channel from the drop-down list box.
RTS/CTS
Threshold
The RTS (Request To Send) threshold (number of bytes) for enabling RTS/CTS
handshake. Data with its frame size larger than this value will perform the RTS/CTS
handshake. Setting this attribute to be larger than the maximum MSDU (MAC
service data unit) size turns off the RTS/CTS handshake. Setting this attribute to
zero turns on the RTS/CTS handshake.
Enter a value between 0 and 2432.
