Prestige 662H/HW Series User’s Guide
Chapter 28 Menu 3 LAN Setup 314
Figure 157 Menu 3.2 TCP/IP and DHCP Ethernet Setup
Follow the instructions in the following table on how to configure the DHCP fields.
Follow the instructions in the following table to configure TCP/IP parameters for the Ethernet port.
Menu 3.2 - TCP/IP and DHCP Setup
DHCP Setup
DHCP= Server
Client IP Pool Starting Address= 192.168.1.33
Size of Client IP Pool= 32
Primary DNS Server= 0.0.0.0
Secondary DNS Server= 0.0.0.0
Remote DHCP Server= N/A
TCP/IP Setup:
IP Address= 192.168.1.1
IP Subnet Mask= 255.255.255.0
RIP Direction= None
Version= N/A
Multicast= None
IP Policies=
Edit IP Alias= No
Press ENTER to Confirm or ESC to Cancel:
Table 109 DHCP Ethernet Setup
FIELD DESCRIPTION
DHCP Setup
DHCP If set to Server, your Prestige can assign IP addresses, an IP default
gateway and DNS servers to Windows 95, Windows NT and other systems
that support the DHCP client.
If set to None, the DHCP server will be disabled.
If set to Relay, the Prestige acts as a surrogate DHCP server and relays
DHCP requests and responses between the remote server and the clients.
Enter the IP address of the actual, remote DHCP server in the Remote
DHCP Server in this case.
When DHCP server is used, the following items need to be set:
Client IP Pool Starting
Address
This field specifies the first of the contiguous addresses in the IP address
pool.
Size of Client IP Pool This field specifies the size or count of the IP address pool.
Primary DNS Server
Secondary DNS Server Enter the IP addresses of the DNS servers. The DNS servers are passed to
the DHCP clients along with the IP address and the subnet mask.
Remote DHCP Serve If Relay is selected in the DHCP field above then enter the IP address of the
actual remote DHCP server here.
Table 110 TCP/IP Ethernet Setup
FIELD DESCRIPTION
TCP/IP Setup
IP Address Enter the (LAN) IP address of your Prestige in dotted decimal notation
