Prestige 662H/HW Series User’s Guide
357
Chapter 34 Network Address Translation (NAT)
Figure 199 Example 3: Final Menu 15.1.1
Now configure the IGA3 to map to our web server and mail server on the LAN.
1 Enter 15 from the main menu.
2 Enter 2 in Menu 15 - NAT Setup.
3 Enter 1 in Menu 15.2 - NAT Server Sets to see the following menu. Configure it as
shown.
Menu 15.1.1 - Address Mapping Rules
Set Name= Example3
Idx Local Start IP Local End IP Global Start IP Global End IP Type
--- --------------- --------------- --------------- --------------- ------
1. 192.168.1.10 10.132.50.1 1-1
2 192.168.1.11 10.132.50.2 1-1
3. 0.0.0.0 255.255.255.255 10.132.50.3 M-1
4. 10.132.50.3 Server
5.
6.
7.
8.
9.
10.
Action= Edit Select Rule=
Press ENTER to Confirm or ESC to Cancel:
