Prestige 662H/HW Series User’s Guide
315
Chapter 28 Menu 3 LAN Setup
IP Subnet Mask
Your Prestige will automatically calculate the subnet mask based on the IP address
that you assign. Unless you are implementing subnetting, use the subnet mask
computed by the Prestige (refer to the
IP Subnetting
appendix for more information).
RIP Direction
Press [
SPACE BAR
] to select the RIP direction. Choices are Both, In Only, Out
Only or None.
Version
Press [
SPACE BAR]
to select the RIP version. Choices are RIP-1, RIP-2B or RIP-
2M.
Multicast
IGMP (Internet Group Multicast Protocol) is a network-layer protocol used to
establish membership in a Multicast group. The Prestige supports both IGMP
version 1 (IGMP-v1) and version 2 (IGMP-v2). Press the [
SPACE BAR]
to enable
IP Multicasting or select None to disable it.
IP Policies
Create policies using SMT menu 25 (see
) and apply
them on the Prestige LAN interface here. You can apply up to four IP Policy sets
(from twelve) by entering their numbers separated by commas.
Edit IP Alias
The Prestige supports three logical LAN interfaces via its single physical Ethernet
interface with the Prestige itself as the gateway for each LAN network. Press
[
SPACE BAR
] to change No to Yes and press [
ENTER
] to display Menu 3.2.1.
Table 110 TCP/IP Ethernet Setup (continued)
FIELD
DESCRIPTION
