Prestige 662H/HW Series User’s Guide
Chapter 14 Firewall Configuration 160
2 What direction of traffic does the rule apply to (refer to the Firewall Policies Overview
section)?
3 What IP services will be affected?
4 What computers on the LAN or DMZ are to be affected (if any)?
5 What computers on the Internet will be affected? The more specific, the better. For
example, if traffic is being allowed from the Internet to the LAN, it is better to allow only
certain machines on the Internet to access the LAN.
14.3.2 Security Ramifications
1 Once the logic of the rule has been defined, it is critical to consider the security
ramifications created by the rule:
2 Does this rule stop LAN users from accessing critical resources on the Internet? For
example, if IRC is blocked, are there users that require this service?
3 Is it possible to modify the rule to be more specific? For example, if IRC is blocked for all
users, will a rule that blocks just certain users be more effective?
4 Does a rule that allows Internet users access to resources on the LAN create a security
vulnerability? For example, if FTP ports (TCP 20, 21) are allowed from the Internet to the
LAN, Internet users may be able to connect to computers with running FTP servers.
5 Does this rule conflict with any existing rules?
6 Once these questions have been answered, adding rules is simply a matter of plugging the
information into the correct fields in the web configurator screens.
14.3.3 Key Fields For Configuring Rules
14.3.3.1 Action
Should the action be to Block or Forward?
14.3.3.2 Service
Select the service from the Service scrolling list box. If the service is not listed, it is necessary
to first define it. See the
Predefined Services section for more information on predefined
services.
14.3.3.3 Source Address
What is the connection’s source address; is it on the LAN, DMZ, WAN? Is it a single IP, a
range of IPs or a subnet?
Note: “Block” means the firewall silently discards the packet.
