Prestige 662H/HW Series User’s Guide
387 Chapter 39 System Information and Diagnosis
To get to System Status, type 24 to go to Menu 24 — System Maintenance. From this menu,
type 1. System Status. There are two commands in Menu 24.1 — System Maintenance —
Status. Entering 1 resets the counters; [ESC] takes you back to the previous screen.
The following table describes the fields present in Menu 24.1 — System Maintenance —
Status which are read-only and meant for diagnostic purposes.
Figure 230 Menu 24.1 System Maintenance : Status
The following table describes the fields present in Menu 24.1 — System Maintenance —
Status.
Menu 24.1 - System Maintenance - Status 00:36:37
Sat. Jan. 01, 2000
Node-Lnk Status TxPkts RxPkts Errors Tx B/s Rx B/s Up
Time
1-PPPoA N/A 0 0 0 0 0 0:00:00
2 N/A 0 0 0 0 0 0:00:00
3 N/A 0 0 0 0 0 0:00:00
4 N/A 0 0 0 0 0 0:00:00
5 N/A 0 0 0 0 0 0:00:00
6 N/A 0 0 0 0 0 0:00:00
7 N/A 0 0 0 0 0 0:00:00
My WAN IP (from ISP): 0.0.0.0
Ethernet: WAN:
Status: Tx Pkts: 528 Line Status: Down
Collisions: 0 Rx Pkts: 505 Upstream Speed: 0 kbps
CPU Load = 2.12% Downstream Speed: 0 kbps
Press Command:
COMMANDS: 1-Reset Counters ESC-Exit
Table 136 Menu 24.1 System Maintenance : Status
FIELD DESCRIPTION
Node-Lnk This is the node index number and link type. Link types are: PPP, ENET, 1483.
Status This shows the status of the remote node.
TxPkts The number of transmitted packets to this remote node.
RxPkts The number of received packets from this remote node.
Errors The number of error packets on this connection.
Tx B/s This shows the transmission rate in bytes per second.
Rx B/s This shows the receiving rate in bytes per second.
Up Time This is the time this channel has been connected to the current remote node.
My WAN IP (from
ISP)
This is the IP address of the ISP remote node.
Ethernet This shows statistics for the LAN.
Status This shows the current status of the LAN.
Tx Pkts This is the number of transmitted packets to the LAN.
