Prestige 662H/HW Series User’s Guide
291 Chapter 24 Maintenance
Figure 141 Diagnostic: General
The following table describes the fields in this screen.
24.6.2 Diagnostic DSL Line Screen
Click Diagnostic and then DSL Line to open the screen shown next.
Table 96 Diagnostic: General
LABEL DESCRIPTION
TCP/IP
Address
Type the IP address of a computer that you want to ping in order to test a connection.
Ping Click this button to ping the IP address that you entered.
Reset System Click this button to reboot the Prestige. A warning dialog box is then displayed asking
you if you're sure you want to reboot the system. Click OK to proceed.
Back Click this button to go back to the main Diagnostic screen.
