Prestige 662H/HW Series User’s Guide
219 Chapter 19 VPN Screens
19.3 My IP Address
My IP Address is the WAN IP address of the Prestige. The Prestige has to rebuild the VPN
tunnel if the My IP Address changes after setup.
The following applies if this field is configured as 0.0.0.0:
• The Prestige uses the current Prestige WAN IP address (static or dynamic) to set up the
VPN tunnel.
• If the WAN connection goes down, the Prestige uses the dial backup IP address for the
VPN tunnel when using dial backup or the LAN IP address when using traffic redirect.
See the chapter on WAN for details on dial backup and traffic redirect.
Table 66 AH and ESP
ESP AH
ENCRYPTION
DES (default)
Data Encryption Standard (DES) is a widely
used method of data encryption using a
private (secret) key. DES applies a 56-bit key
to each 64-bit block of data.
MD5 (default)
MD5 (Message Digest 5) produces a 128-bit
digest to authenticate packet data.
3DES
Triple DES (3DES) is a variant of DES, which
iterates three times with three separate keys
(3 x 56 = 168 bits), effectively doubling the
strength of DES.
SHA1
SHA1 (Secure Hash Algorithm) produces a
160-bit digest to authenticate packet data.
AES
Advanced Encryption Standard is a newer
method of data encryption that also uses a
secret key. This implementation of AES
applies a 128-bit key to 128-bit blocks of data.
AES is faster than 3DES.
Select NULL to set up a phase 2 tunnel
without encryption.
AUTHENTICATION
MD5 (default)
MD5 (Message Digest 5) produces a 128-bit
digest to authenticate packet data.
MD5 (default)
MD5 (Message Digest 5) produces a 128-bit
digest to authenticate packet data.
SHA1
SHA1 (Secure Hash Algorithm) produces a
160-bit digest to authenticate packet data.
SHA1
SHA1 (Secure Hash Algorithm) produces a
160-bit digest to authenticate packet data.
Select MD5 for minimal security and SHA1 for maximum security.
