Prestige 662H/HW Series User’s Guide
Chapter 24 Maintenance 290
Figure 140 Association List
The following table describes the fields in this screen.
24.6 Diagnostic Screens
These read-only screens display information to help you identify problems with the Prestige.
24.6.1 Diagnostic General Screen
Click Diagnostic and then General to open the screen shown next.
Table 95 Association List
LABEL DESCRIPTION
# This is the index number of an associated wireless station.
MAC Address This field displays the MAC (Media Access Control) address of an associated wireless
station.
Every Ethernet device has a unique MAC address. The MAC address is assigned at
the factory and consists of six pairs of hexadecimal characters, for example,
00:A0:C5:00:00:02.
Association
Time
This field displays the time a wireless station is associated to the Prestige.
Back Click Back to return to the previous screen.
Refresh Click Refresh to renew the information in the table.
