Prestige 662H/HW Series User’s Guide
Chapter 27 Menu 2 WAN Backup Setup 310
Figure 154 Menu 2.2.1 Advanced Dial Backup Setup
The following table describes fields in this menu.
Menu 2.2.1 - Advanced Dial Backup Setup
AT Command Strings: Call Control:
Dial= atd Dial Timeout(sec)= 60
Drop= ~~+++~~ath Retry Count= 0
Answer= ata Retry Interval(sec)= N/A
Drop Timeout(sec)= 20
Drop DTR When Hang Up= No Call Back Delay(sec)= 15
AT Response Strings:
CLID= NMBR =
Called Id=
Speed= CONNECT
Press ENTER to Confirm or ESC to Cancel:
Table 107 Menu 2.2.1 Advanced Dial Backup Setup: AT Commands Fields
FIELD DESCRIPTION
AT Command Strings:
Dial Enter the AT Command string to make a call.
Drop Enter the AT Command string to drop a call. "~” represents a one second wait,
e.g., " ~~~+++~~ath " can be used if your modem has a slow response time.
Answer Enter the AT Command string to answer a call.
Drop DTR When
Hang Up
Press the [SPACE BAR] to choose either Yes or No. When Yes is selected
(the default), the DTR (Data Terminal Ready) signal is dropped after the " AT
Command String: Drop " is sent out.
AT Response Strings:
CLID (Calling Line
Identification)
Enter the keyword that precedes the CLID (Calling Line Identification) in the AT
response string. This lets the Prestige capture the CLID in the AT response
string that comes from the WAN device. CLID is required for CLID
authentication.
Called Id Enter the keyword preceding the dialed number.
Speed Enter the keyword preceding the connection speed.
Table 108 Menu 2.2.1 Advanced Dial Backup Setup: Call Control Parameters
FIELD DESCRIPTION
Call Control
Dial Timeout (sec) Enter a number of seconds for the Prestige to keep trying to set up an outgoing
call before timing out (stopping). The Prestige times out and stops if it cannot
set up an outgoing call within the timeout value.
Retry Count Enter a number of times for the Prestige to retry a busy or no-answer phone
number before blacklisting the number.
Retry Interval (sec) Enter a number of seconds for the Prestige to wait before trying another call
after a call has failed. This applies before a phone number is blacklisted.
