Prestige 662H/HW Series User’s Guide
Appendix M 506
Appendix M
Example Internal SPTGEN Screens
This appendix covers Prestige Internal SPTGEN screens.
The following are Internal SPTGEN screens associated with the SMT screens of your Prestige.
Example Internal SPTGEN Screens Table
Table 18 Abbreviations Used in the Example Internal SPTGEN Screens Table
ABBREVIATION MEANING
FIN Field Identification Number (not seen in SMT screens)
FN Field Name
PVA Parameter Values Allowed
INPUT An example of what you may enter
* Applies to the Prestige.
Table 19 Menu 1 General Setup (SMT Menu 1)
/ Menu 1 General Setup (SMT Menu 1)
FIN FN PVA INPUT
10000000 = Configured <0(No) | 1(Yes)> = 0
10000001 = System Name = Prestige
10000002 = Location =
10000003 = Contact Person's Name =
10000004 = Route IP <0(No) | 1(Yes)> = 1
10000006 = Bridge <0(No) | 1(Yes)> = 0
Table 20 Menu 3 (SMT Menu 1)
/ Menu 3.1 General Ethernet Setup (SMT menu 3.1)
FIN FN PVA INPUT
30100001 = Input Protocol filters Set 1 = 2
30100002 = Input Protocol filters Set 2 = 256
30100003 = Input Protocol filters Set 3 = 256
30100004 = Input Protocol filters Set 4 = 256
30100005 = Input device filters Set 1 = 256
30100006 = Input device filters Set 2 = 256
30100007 = Input device filters Set 3 = 256
