1. EXTERNAL VIEW
1
Document Guide
8
Scanner Release
2
Document Table
9
Lifting Handle
3
Operation Panel
10
Front Cover Release
4
Telephone: optional
11
Cassette
5
Manual Feed Button
12
Copy Tray
6
Document Tray
13
Lower Cassette(s) or Drawers:
optional (see the next page). Up
to 4 units can be added below
the upper cassette.
7
Power Switch (on the rear)
14
Base: optional (see the next
page)
SECTION 1. COMPONENT GUIDE
2
3
4
5
6
7
8
9
10
11
12
1
14
