Ricoh FAX4500L User Manual

Page 106

Text mode
Original mode

1. REPLACING PAPER

❐ When the Add Paper indicator ( ) on the operation panel is lit, the upper

cassette is empty.

❐ When the Add Paper indicator ( ) on the lower cassette is lit, the lower

cassette is empty (only when the lower cassette is installed).

To refill either cassette:

1. Slide the cassette all the way out, and

place it on a large flat surface.

CAUTION
To avoid dropping the cassette, hold it
by the front and side while pulling it
out.
If there is a paper feed problem in the
lower cassette entrance, please slide
out the cassettes one by one, from the
top cassette down, before removing
the paper.

2. Bend the new stack of paper a few

times.

3. Load the paper into the cassette.

NOTE: ❐ True up the edges of the

stack.

❐ Do not fill up the cassette

past the load limit marker.

4. Replace the cassette carefully.

SECTION 6. LOOKING AFTER THE MACHINE
