6. Clean the separation roller [E] with
the soft damp cloth, while rotating
the roller. This roller is near the
➀
decal.
7. Clean the white strip [F] with the soft
damp cloth.
CAUTION:
Do not damage the sensor actuator
[G] (black plastic) below the white strip.
8. Clean the R1 and R2 rollers [H] with
the soft damp cloth. To rotate the roll -
ers, gently hold the cloth down on the
rollers and turn the main power
switch on. The rollers will rotate
once. These rollers are near the
➂
decal.
[H]
[F]
[G]
[E]
