The Results Column
OK: Successful Communication
E: An error occurred
The Footnote on the Reports
TX: Total number of transmitted pages
RX: Total number of received pages
On the User Parameter List, you will also see the following counter:
OPU Counter:
Total number of pages printed so far with the current
master unit.
In the Result column, some reports may have an "E" followed by a code, and
there may be a message printed at the bottom of the report. This code and mes -
sage indicate that a problem occurred. The codes are explained below.
CODE
MESSAGE
EXPLANATION
1
HANG UP OR LINE FAIL
The other party either a) hung up, b) had
no message on polling standby, c) cannot
do confidential reception or transfer
request, or d) had an ID Code that did not
match the one in your machine.
Alternatively, there could have been a
problem with the telephone line.
2
BUSY
The machine at the other end was busy.
3
NO ANSWER
The line is dead (no dial tone was
detected).
4
NO FACSIMILE
CONNECTION
The machine at the other end did not
answer.
