42 Aries User Guide
Table 15 lists part numbers (at time of publication) for suitable fuses from
several manufacturers. These fuses are type RK5 (time delay fuses).
Amps Bussmann
Ferraz
Shawmut
(formerly
Gould)
Littelfuse
10 FRN-R-10 TR10R FLNR10
20 FRN-R-20 TR20R FLNR20
30 FRN-R-30 TR30R FLNR30
40 FRN-R-40 TR40R FLNR40
Table 15 Fuse Part Numbers
Drive Inrush Current
The drive inrush current is limited by an internal thermistor that changes
value with the ambient temperature. Drive inrush current is therefore
dependent upon the temperature of the surrounding environment (T
amb
). To
determine the drive inrush current for your drive, see Table 16.
Drive Type AC Voltage Drive Inrush
(25°C T
amb
)
Drive Inrush
(50°C T
amb
)
120 VAC 34A 73A
AR-01xx
240 VAC 68A 146A
120 VAC 34A 73A
AR-02xx
240 VAC 68A 146A
120 VAC 17A 36A
AR-04xx
240 VAC 34A 73A
120 VAC 17A 36A
AR-08xx
240 VAC 34A 73A
120 VAC 17A 36A
AR13xE
240 VAC 34A 73A
AR-20xE 240 VAC 68A 155A
AR-30xE 240 VAC 68A 155A
Table 16 Drive Motor Power Inrush Current
