150 Aries User Guide
TMTEMP Transfer Motor Temperature
Type Transfer Product Rev
Syntax TMTEMP Aries 1.0
Units Degrees Celsius
Range N/A
Default N/A
Response TMTEMP: <*>45
See Also DMTRWC , DMTTCM , DMTTCW , STATUS , TERRLG
The TMTEMP reports the predicted temperature of the motor winding for
Parker motors. The temperature is estimated using the winding and motor
time constants, the rated continuous current, and the winding thermal
resistance. The motor will fault (and the drive reports E35–Motor Thermal
Model Fault) at an estimated winding temperature of 125°C, assuming
the ambient temperature is 40°C.
In OS 2.10, If DMTSWT equals 3, and the thermal temperature is greater than
60
°C, TMTEMP reports the higher of the motor model thermistor temperature
or the NTC thermistor temperature.
If you are using a non-Parker motor, the TMTEMP value depends on
parameters you supply for DMTRWC, DMTTCM and DMTTCW.
TOUT Transfer Output Status
Type Transfer Product Rev
Syntax TOUT Aries 1.0
Units N/A
Range Ø (inactive) or 1 (active)
Default N/A
Response TOUT: <*>ШШШШ_ШШШШ_ШШШШ_ШШ11
See Also none
The TOUT command returns the present status of the brake relay (bit 1) and
fault output (bit 0). Bits 2 through 15 are reserved. The return of one (1)
indicates the relevant output is active and a zero (Ø) indicates it is inactive.
