1-7
(2) Driver part
! 500W level
(A model with regenerative terminal is shown)
Setting switch
and status LED
display part
Connection of power
supply and motor cable
RS232C
connnector
Sensor brake
terminal
Contact I/O connector 1
Analog monitor connector
Encoder resolver connector
Mounting bracket
Mounting bracket
! 2kW level
(A model with a regenerative terminal is shown)
Heat sink
Regenerative unit
1
