Appendix D: Full Connectivity Diagram
16 channel model shown
*DVI to VGA converter included.
(Not Included)
PC
(Not Included)
BNC CAMERAS
LINE IN AUDIO from Audio
Capable Cameras/
AMPLIFIED SPEAKERS
(not included)
DVI/VGA MONITOR*
(not included)
(Not Included)
Flex IR Extender
USB Port
EDGE
+
Series
