91
Appendix A: System Specifications
Edge
+
and Edge Mini Specifications
SYSTEM
Operating System Linux (embedded)
Pentaplex Simultaneous View, Record, Playback, Backup & Remote Monitoring
Number of Channels 4 Channel (Edge mini)
4/8/16 Channel (Edge & Edge+)
INPUTS/OUTPUTS
Video IN 4/8/16 x 1Vp-p, 75ohms, BNC
DVI Out* DVI compatible. DVI to VGA Converter included.
VGA Out Only available in Edge 4ch & Edge mini
Audio IN 2 Line in(RCA)
Audio Out 2 line out(RCA)
USB Port 2 front & back
Alarm IN** 4 x TTL, programmable as NC/NO
Alarm Out** 1 x Relay with NO/NC contact
PTZ control*** By Terminal connector (RS485)
DISPLAY
Live Display 1 or 4 (4ch)
1 or 4 or 9 (8ch)
1 or 4 or 9 or 16 (16ch)
Live Display Speed 120 (4ch)/ 240 (8ch)/ 240 (16ch) NTSC
100 (4ch)/ 200 (8ch)/ 200 (16ch) PAL
OSD ON/OFF
Activity Detection 6 x 8 grid
Sensitivity levels 100
System Control USB Mouse, Handheld Remote Control & Flex IR**
Front Panel Controls***
Firmware Upgrade Via USB device
User Authority ADMIN/USER/GUEST
RECORDING
Video Compression H.264
Audio Compression ADPCM
*Not included in Edge 4ch and Edge mini
**Not included in Edge mini
***Only included in Edge+
