90
Appendix A: System Specifications
Appendix A: System Specifications (cont’d.)
EDGE SERIES DVR
Product Information
EDGE SERIES 4/8/16-channel
Description Specification
4CH 8CH 16CH
Alarm inputs 4 x TTL 4 x TTL, programmable as NC/NO
Alarm outputs 1 x relay with NO/NC contact
Activity detection 4 x 3 grid, sensitivity levels: 100 8 x 6 grid, sensitivity levels: 100
Remote functions Live view, live recording, search, setup, backup
Network speed
control 10 levels (28.8Kb~8MB) / sec.
Network protocol TCP/IP, DDNS, Web
Network interface 10 / 100Mbps Base-TX, RJ-45
Description Specification
Unit Weight 3.19 lbs / 1.45 kg
Unit Dimensions
(WxHxD) 11.4" x 1.6" x 7.0"
290 mm x 42 mm x 180 mm
Front
Side
