MC9000-G Product Reference Guide for Embedded Windows® CE .NET
1-14
Strap Lanyard
The strap lanyard may be moved to either the left or right side of the mobile computer to suite user
preferences.
To reposition the strap lanyard:
1.
Disconnect the strap lanyard disconnect clip.
2.
Open loop and slide the disconnect clip through the loop.
3.
Slide the loop out of the connector post.
4.
Repeat procedure on remaining connector to remove strap lanyard.
5.
Reverse procedure to re-attach the strap lanyard. Two strap lanyard connectors are provided
on the mobile computer’s main body, the strap lanyard cord may be attached to either
connector.
Figure 1-6. Reposition the Strap Lanyard
Strap Lanyard Connectors
Strap Lanyard
Cord Loop
Strap Lanyard
Disconnect Clip
Loop Connection Details
