4. OPERATION
(Note 2) Input signals
(Note 1) DI4
(Note 1) DI3
(Note 1) DI2
DI1
DI0
Selected point table No.
0
0
0
0
0
0 (Manual home position return mode)
0 0 0 0 1
1
0 0 0 1 0
2
0 0 0 1 1
3
0 0 1 0 0
4
0 0 1 0 1
5
0 0 1 1 0
6
0 0 1 1 1
7
0 1 0 0 0
8
0 1 0 0 1
9
0 1 0 1 0
10
0 1 0 1 1
11
0 1 1 0 0
12
0 1 1 0 1
13
0 1 1 1 0
14
0 1 1 1 1
15
1 0 0 0 0
16
1 0 0 0 1
17
1 0 0 1 0
18
1 0 0 1 1
19
1 0 1 0 0
20
1 0 1 0 1
21
1 0 1 1 0
22
1 0 1 1 1
23
1 1 0 0 0
24
1 1 0 0 1
25
1 1 0 1 0
26
1 1 0 1 1
27
1 1 1 0 0
28
1 1 1 0 1
29
1 1 1 1 0
30
1 1 1 1 1
31
Note 1. Make signals valid in "I/O Devices" on the MR Configurator (servo configuration software).
2. "1": short
"0": open
