5 - 6
5. PARAMETERS
Class No. Symbol Name and Function
Initial
value
Unit
Setting
range
2 *OP1 Function selection 1
Used to select the input filter and absolute position detection system.
Input filter
If external input signal causes chattering due
to noise, etc., input filter is used to suppress it.
0: None
1: 0.88[ms]
2: 1.77[ms]
3: 2.66[ms]
4: 3.55[ms]
5: 4.44[ms]
Selection of absolute position detection system
(Refer to section 4.5)
0: Incremental system
1: Absolute position detection system
0 0
0002 Refer to
Name
and
function
column.
B
asi
c pa
ra
met
ers
3 ATU
Auto tuning
Used to selection the response level, etc. for execution of auto tuning.
(Refer to chapter 7)
Auto tuning response level setting
If the machine hunts or generates large gear sound,
decrease the set value.
To improve performance, e.g. shorten the settling time,
increase the set value.
Set
value
Response
level
1 Low
response
Middle
response
High
response
Gain adjustment mode selection
(For more information, refer to section 8.1.1.)
Machine resonance
frequency guideline
15Hz
2 20Hz
3 25Hz
4 30Hz
5 35Hz
6 45Hz
7 55Hz
8 70Hz
9 85Hz
A 105Hz
B 130Hz
C 160Hz
D 200Hz
E 240Hz
F 300Hz
Set value Gain adjustment mode
0
Description
1
3 Simple manual adjustment.
4 Manual adjustment of all gains.
Interpolation mode Fixes position control gain 1
(parameter No. 6).
Auto tuning mode 1
Fixes the load inertia moment
ratio set in parameter No. 34.
Response level setting can be
changed.
Manual mode 1
Manual mode 2
2 Auto tuning mode 2
Ordinary auto tuning.
0 0
0105 Refer to
Name
and
function
column .
