14. OPTIONS AND AUXILIARY EQUIPMENT
(c) MR-RB50 MR-RB51
[Unit: mm (in)]
Terminal block
G4
G3
C
P
Terminal screw: M4
Tightening torque: 1.2 [N m]
(10.6 [Ib in])
Mounting screw
Screw: M6
Tightening torque: 5.4 [N m]
(47.79 [Ib in])
Regenerative
option
Mass [kg] (Ib)
MR-RB50
MR-RB51
5.6 (12.3)
2.3
(0.09)
49
(1.93)
82.5
(3.25)
200 (7.87)
217 (8.54)
17
(0.67) 8 (0.32) 120 (4.73)
108 (4.25) 12
(0.47)
7 (0.28)
Approx.30 (1.18)
7 14
slot
Fan mounting screw
(2-M3 screw)
On opposite side
Wind blows in the
arrow direction
