1 - 25
1. FUNCTIONS AND CONFIGURATION
(4) MR-J2S-700CP
MR Configurator
(Servo configuration software)
Regenerative option
Chapter 6
Section 14.1.1
Options and auxiliary equipment
Circuit breaker
Magnetic contactor
Reference
Section 14.2.2
Section 14.2.2
Options and auxiliary equipment Reference
Cables
Manual pulse generator
External digital display
Section 14.2.1
Section 14.1.8
Section 14.1.7
Power factor improving reactor Section 14.2.3
Command device
Junction terminal
block
Manual pulse
generator
External digital display
Personal
computer
MR Configurator
(Servo
configuration
software
MRZJW3-
SETUP151E)
To CN1A
To CN1B
To CN3
To CN2
(Note 1)
U
V
W L
1
L
2
L
3
Power
factor
improving
reactor
(FR-BAL)
Magnetic
contactor
(MC)
L
11
L
21
Circuit
breaker
(NFB) or
fuse
(Note 2)
Power supply
Servo amplifier
P C
Regenerative option
Note 1. When using the regenerative option, remove the lead wires of the built-in regenerative resistor.
2. Refer to section 1.2 for the power supply specification.
