14. OPTIONS AND AUXILIARY EQUIPMENT
(4) Outline dimension drawings
(a) FR-BU2 brake unit
[Unit: mm]
FR-BU2-15K
Rating
plate
5 hole
(Screw size: M4)
68
6
56
6
5
18.5
52
62
4
132.5
FR-BU2-30K
129.5
5
59
18.5
Rating
plate
52
2- 5 hole
(Screw size: M4)
5
108
6
6
96
