Programming
80 MS-9200UDLS PN 52750:E1 01/27/09
Monitor module type selection will affect the function of the point as follows:
Note:
1. For entries ending in AR, AR refers to AutoResettable
2. For HVAC RESTART and HVAC OVRRIDE descriptions, refer to "Monitor
Module Operation" on page 208
3. Combination systems employing these non-fire monitor types require the SLC
loop to be programmed by the installer for Style 4 operation and isolator
modules must be employed on each non-fire branch of the SLC as per Figure 13
in the SLC Wiring Manual (document number 51309). Fire and non-fire devices
must not be used on the same SLC branch.
Table 3.1 Monitor Types
Monitor Type Action When Activated
Pull-Station Fire Alarm
User-Defined-1 same as previous (Pull-Station)
Waterflow Fire Alarm Delayed
User-Defined-2 same as previous (Waterflow)
Monitor Fire Alarm
User-Defined-3 same as previous (Monitor)
Future not used
Future not used
Smoke-Conventional Fire Alarm
User-Defined-5 same as previous (Smoke-Conventional)
Heat-Conventional Fire Alarm
User-Defined-6 same as previous (Heat-Detector)
Medic-Alert 3 Supervisory, latching
User-Defined-7 same as previous (Medic-Alert)
Hazard-Alert 3 Supervisory, latching
User-Defined-8 same as previous (Hazard-Alert)
Tornado-Alert 3 Supervisory, latching
User-Defined-9 same as previous (Tornado-Alert)
Phone Active Phone (LCD display only)
User-Defined-10 same as previous (Phone)
Tamper Supervisory, nonlatching (tracking)
User-Defined-11 same as previous (Tamper)
Supervisory Supervisory, latching
User-Defined-12 same as previous (Supervisory)
Supervisory-AR 1 Supervisory, nonlatching (tracking)
User-Defined-13 same as previous (Supervisory-AR)
HVAC OVRRIDE 2 Switch Supervisory, nonlatching (tracking)
Power-Monitor Power Fault
User-Defined-14 same as previous (Power Monitor)
Trouble-Monitor Trouble
User-Defined-15 same as previous (Trouble Monitor)
Process-Monitor 3 Piezo
User-Defined 16 same as previous (Process-Monitor)
Process-Monitor-AR 1, 3 Piezo, nonlatching (tracking)
User-Defined-17 same as previous (Process-Monitor-AR)
Future not used
Future not used
Ack-Switch Acts like panel Acknowledge Key
Sil-Switch Acts like panel Silence Key
Reset-Switch Acts like panel Reset Key
Drill-Switch Acts like panel Drill Key
PAS-Bypass PAS Disable
HVAC RESTART 2 Switch (see note 2)
Drill-Switch-AR 1 Acts like panel Drill Key, nonlatching (tracking)
