The Annunciator Screen indicates if Terminal mode options are enabled or disabled.
Pressing 2 for ACS Options while viewing the Annunciator Screen allows the operator
to view the ACS Options screen:
The ACS Options screen indicates if the ACS option has been enabled YES or disabled
NO.
Pressing 2 for ACS Addresses while viewing the ACS Options screen will display
screens with ACS addresses 1 -31 and whether a device is installed at that address YES
or not installed NO.
The ACS Options screen indicates if a UDACT is installed YES or if a UDACT is not
installed NO.
Pressing 3 for ANN-BUS Options while viewing the Annunciator Screen will display
the following screens:
The ANN-BUS Screen #1 indicates if the ANN-BUS has been enabled YES or disabled
NO.
Pressing 2 for Modules Installed while viewing ANN-BUS Screen #1 will display
screens for ANN-BUS Addresses 1 -8 and the devices installed at each address.
Subscreen will display the options that have been programmed for each device.
Pressing 3 for ANN-S/PG Options while viewing ANN-BUS Screen #1 will display the
options selected for the installed serial or parallel printer.
Pressing 1 for ANN-80 Options while viewing ANN-BUS Screen #2 will display the
options selected for the installed ANN-80 annunciators.
ACS OPTIONS
ACS ENABLED NO
2=ACS ADDRESSES
UDACT ENABLED NO
ACS Options Screen
ANN-BUS
ENABLED NO
2=MODULES INSTALLED
3=ANN-S/PG OPTIONS
ANN-BUS Screen #1
ANN-BUS
1=ANN-80 OPTIONS
ANN-BUS Screen #2
