Programming
MS-9200UDLS PN 52750:E1 01/27/09 67
If no detectors have been installed on the loop, the following will be displayed:
If the selected address has been added to programming, device summary screens
will be displayed. These screens allow the programmer to view all device settings
at a single glance. Pressing the left or right arrow keys will allow the programmer
to rapidly view the devices at the previous or next address (if installed).
If a detector (such as a photoelectric detector) with the selected address is not
physically installed on the SLC or has a communication fault but the address is
programmed in the system, the following screen will be displayed:
If the selected address has been added to programming and a detector (such as a
photoelectric detector) with the selected address is physically installed on the SLC
and is communicating with the control panel, the following will be displayed:
To change the programming for the displayed detector, press the keyboard ‘down’
arrow key to view the Edit Detector screens.
In the preceding example:
Normal - indicates that the detector with the selected address is physically
installed on the SLC and communicating with the control panel (enabled)
- represents the adjective and noun, which have been
programmed, describing the location of the displayed device
ZNNN - represents the first of five possible software zones that the detector is
assigned to (NNN = the three digit zone number from 000 - 099)
V or * - indicates whether or not alarm verification is enabled (V = alarm
verification enabled and * = alarm verification disabled)
1D017 - represents the Loop, Device type and Device address (1 = SLC Loop,
D=Detector and 017 = Detector Address 017)
NO DETECTOR
INSTALLED
Edit Detector Screen #1
TROUBL SMOKE(PHOTO)
ZNNN
* 1D017
Edit Detector Screen #1
NORMAL SMOKE (PHOTO)
ZNNN
V 1D017
Edit Detector Screen #1
