ANN-LED Options
Pressing 2 for Module Options while viewing ANN-BUS Address Screen when the
ANN-LED option is selected, will display the following screen:
The first screen indicates that the ANN-LED at the selected ANN-BUS address is
programmed to annunciate Alarms, Supervisories and Troubles for SLC Loop #1
addressable Detectors with addresses 1 through 10. The programming can be
changed using ANN-LED Address Screens 2 and 3.
Pressing 1 while viewing ANN-LED Address Screen #2 will program the
annunciator module to annunciate either Point (addressable device address)
information or Zone information.
Pressing 2 while viewing ANN-LED Address Screen #2 will program the
annunciator module to annunciate only Alarms for addressable device addresses 1-
30 or Alarms, Supervisories and Troubles for addressable device addresses 1-10.
Pressing 1 while viewing ANN-LED Address Screen #3 will select the Point or
Zone range to be annunciated - refer to the tables in "ANN-LED Zone Option -
Alarm Only (for use with ANN-RLED module)" on page 124 and "ANN-LED
Point Option - Alarm Only (for use with ANN-RLED module)" on page 126.
Pressing 2 while viewing ANN-LED Address Screen #3 will select either
addressable detectors or addressable modules to be annunciated.
PROGRAMMING
1=ANN-RLY OPTIONS
2=ANN-LED OPTIONS
ANN-BUS Screen #3
ANN-LED ADDR #
LOOP1 DET 1-10
ALARM,SUPERV,TBL
ANN-LED Address Screen #1
ANN-LED ADDR #
1=POINT/ZONE
2=ALARM/ATS
ANN-LED Address Screen #2
ANN-LED ADDR #
1=RANGE
2=DET/MOD
3=LOOP#
ANN-LED Address Screen #3
