Programming
128 MS-9200UDLS PN 52750:E1 01/27/09
ANN-RLY Options
Pressing 2 for Module Options while viewing ANN-BUS Address Screen when the
ANN-RLY option is selected, will cause the following screen to be displayed:
The ANN-RLY module provides ten Form-C relays which can be programmed for
various functions. The initial screen displays Relays 1 through 3. Pressing the
down arrow key will display the remaining relays for this module.
To program any of the ANN-RLY relays, while viewing the appropriate ANN-RLY
Option screen, press the number key corresponding to the relay to be programmed.
Following is a list of the available programming options for each relay:
• Alarm
• Supervisory
• Supervisory AR
• Trouble
• Comm Fail
• Process Mon
• Process Mon AR
• AC Loss
• Hazard
• Medical
• Silenceable Alarm
• Zone Active XX
3.6.9.1.3.3 Auto-Configure
The ANN-BUS Auto-Configure features allows the programmer to quickly bring all
installed ANN-BUS modules online. The software will search for all ANN-BUS
modules and automatically program the device type and address into the system.
For the Auto-Configure to work, the ANN-BUS must be enabled, the annunciators
must be connected/powered and a unique address must be set on each annunciator.
Pressing 3 while viewing ANN-BUS Screen #1 will begin the Auto-Configure
process and cause the following screen to be displayed:
ANN-RLY - ADDR. #
1=RELAY 1 ZONE 00
2=RELAY 2 ZONE 01
3=RELAY 3 ZONE 02
ANN-RLY Options Screen
ANN-BUS
AUTO-CONGFIGURE
IN PROGRESS
PLEASE WAIT
Auto-Configure Screen
