4-28 Using the Performance Manager GUI
Hitachi Universal Storage Platform V/VM Hitachi Performance Manager User’s Guide
Table 4-4 Relationship between the Display of a Cell and the CU Status
in the CU Table
CU Exists CU Monitoring Status Letter Displayed in The Cell
CU is being monitored S: in black
CU is to be released from monitoring R : in blue italics
Yes
CU is not being monitored None
CU will be monitored when it exist N: in black
CU is to be released from monitoring -: Hyphen in black bold
No
CU will not be monitored when it exist -: Hyphen in black
• Monitoring Target CUs:
Indicates the number of existing and newly added CUs to be monitored.
• The Select button adds the CU selected in the CU table to the CUs to be
monitored.
Table 4-5 Characters Indicated in a Cell When the Select Button is
Clicked
Before Click After Click
-: Hyphen in black N: in black italics
R : in blue italics S: in black
• The Release button removes the CU from monitoring targets.
Table 4-6 Characters Indicated in a Cell When Release Button is
Clicked
Before Click After Click
N: in black -: Hyphen in black bold
S: in black R : slanted in blue italics
• The Apply button applies settings in the Monitoring Options window to
the storage system.
• The Reset button resets the settings in the Monitoring Options window.
Performance Monitor has two kinds of periods (ranges) for collecting and
storing statistics: short range and long range.
The storing period of statistics in short range is determined by the settings of
Gathering Interval option. Performance Monitor saves the statistics obtained
up to 1440 times in SVP. Therefore, you can estimate the storing period of
statistics with "gathering interval multiplied by 1440". For example, if you
specify one minute for the gathering interval, the statistics for one day can be
stored at the maximum from the following formula:
1 minute x 1440 = 1440 minutes = 24 hours = 1 day
