7-2

Using the Export Tool

Hitachi Universal Storage Platform V/VM Hitachi Performance Manager User’s Guide

Files to be Exported

The Export Tool allows you to save monitoring data appearing in the
Performance Management window into files. The Export Tool also allows

you to save monitoring data about remote copy operations into files. The
Export Tool usually compresses monitoring data in compressed (ZIP) files. To
use a text editor or spreadsheet software to view or edit the monitoring data,

you usually need to decompress the ZIP files to extract CSV files. However, if
you want the Export Tool to save monitoring data in CSV files instead of ZIP
files, you can force the Export Tool to do so.

Table 7-1 shows the correspondence between the Performance Monitor
windows and the monitoring data that can be saved by the Export Tool. For
details on the ZIP files and CSV files that are saved, refer to the tables

indicated in the See column.

Table 7-1

Performance Management Windows and Monitoring Data
Saved by the Export Tool

Window

Monitoring Data

See

Physical tab in the
Performance
Management Window

Statistics about resource usage and write pending rates

Table 7-2

Statistics about parity groups, external volume groups, or V-
VOL groups

Table 7-3

LDEV tab in the
Performance
Management window

Statistics about volumes in parity groups, in external volume
groups, or in V-VOL groups

Table 7-4

Statistics about ports

Table 7-5

Statistics about host bus adapters connected to ports

Table 7-6

Port-LUN tab in the
Performance
Management window

Statistics about volumes(LUs)

Table 7-7

Statistics about SPM groups

Table 7-8

WWN tab in the
Performance
Management window

Statistics about host bus adapters belonging to SPM groups

Table 7-9

Statistics about remote copy operations by TrueCopy and
TrueCopy for IBM z/OS (in the whole volume)

Table 7-10

Statistics about remote copy operations by TrueCopy and
TrueCopy for IBM z/OS (for each volume (LU))

Table 7-11

Statistics about remote copy operations by TrueCopy and
TrueCopy for IBM z/OS (at volumes controlled by a particular
CU)

Table 7-12

TC Monitor window
and
TCz Monitor window

Statistics about remote copy operations by TrueCopy and
TrueCopy for IBM z/OS (At CLPR)

Table 7-13

Statistics about remote copy operations by Universal Replicator
and Universal Replicator for IBM z/OS (in the whole volume)

Table 7-14

UR Monitor window
and
URz Monitor window

Statistics about remote copy operations by Universal Replicator
and Universal Replicator for IBM z/OS (at journal groups)

Table 7-15
