Using the Export Tool 7-45
Hitachi Universal Storage Platform V/VM Hitachi Performance Manager User’s Guide
Table 7-5.
When you specify variables port-name, you can narrow the range of ports
whose monitoring data are to be exported. port-name is a port name. The
colon (:) indicates a range. For example,
CL3-a:CL3-c
indicates ports from
CL3-a to CL3-c.
Ensure that the port-name value on the left of the colon is smaller than the
port-name value on the right of the colon. The smallest port-name value is
CL1-A and the largest port-name value is CL4-r. The following formula
illustrates which value is smaller than which value:
CL1-A < CL1-B < … < CL2-A < CL2-B < … < CL3-a < CL3-b < … < CL4-
a < … < CL4-r
For example, you can specify
Port CL1-C:CL2-A
, but you cannot specify
Port CL2-A:CL1-C
. Also, you can specify
Port CL3-a:CL3-c
, but you cannot
specify
Port CL3-c:CL3-a
.
If port-name is not specified, the monitoring data of all the ports will be
exported.
PortWWNU[[port-name]:[port-name]][U…]
Use this operand when you want to export statistics about host bus
adapters (WWNs) connected to ports, which are displayed in the Port-LUN
tab of the Performance Management window. When statistics are
exported in a ZIP file, the file name will be PortWWN_dat.ZIP. For details
on the statistics exported by this operand, see Table 7-6.
When you specify variables port-name, you can narrow the range of ports
whose monitoring data are to be exported. port-name is a port name. The
colon (:) indicates a range. For example,
CL3-a:CL3-c
indicates ports from
CL3-a to CL3-c.
Ensure that the port-name value on the left of the colon is smaller than the
port-name value on the right of the colon. The smallest port-name value is
CL1-A and the largest port-name value is CL4-r. The following formula
illustrates which value is smaller than which value:
CL1-A < CL1-B < … < CL2-A < CL2-B < … < CL3-a < CL3-b < … < CL4-
a < … < CL4-r
For example, you can specify
PortWWN CL1-C:CL2-A
, but you cannot specify
PortWWN CL2-A:CL1-C
. Also, you can specify
PortWWN CL3-a:CL3-c
, but you
cannot specify
PortWWN CL3-c:CL3-a
.
If port-name is not specified, the monitoring data of all the host bus
adapters will be exported.
LUU[[port-name.host-group-id]:[port-name.host-group-id]][U…]
Use this operand when you want to export statistics about LU paths, which
are displayed in the Port-LUN tab of the Performance Management
window. When statistics are exported in a ZIP file, the file name will be
LU_dat.ZIP. For details on the statistics exported by this operand, see
