Using the Export Tool 7-13
Hitachi Universal Storage Platform V/VM Hitachi Performance Manager User’s Guide
ZIP File CSV File Data Saved in the File
RCLDEV_Pair_Synchronized.ZI
P RCLDEV_Pair_Synchronized_xx
.csv The percentage of completion of copy operations
(i.e., number of synchronized pairs / total number
of pairs)
RCLDEV_Out_of_Tracks.ZIP RCLDEV_Out_of_Tracks_xx.cs
v The number of tracks that have not yet been
copied by the initial copy or Resync copy operation
Note:
ƒ 1 millisecond is one-thousandth of 1 second.
ƒ The letters "xx" in CSV filenames indicate a CU image number. For example, if the filename is
RCLDEV_All_RIO_10.csv, the file contains the total number of remote I/Os of the volumes controlled by the CU
whose image number is 10.
Table 7-13 Files with Statistics about Remote Copy Operations by TC and
TC for IBM z/OS (At CLPR)
ZIP File CSV File Data Saved in the File
RCCLPR_dat.ZIP RCCLPR_SideFile.csv Sidefile usage rate (percent) per CLPR
Table 7-14 Files with Statistics about Remote Copy Operations by UR and
UR for IBM z/OS (In the Whole Volumes)
ZIP File CSV File Data Saved in the File
UniversalReplicator.ZIP UniversalReplicator.csv The following data in the whole volumes are
saved:
ƒ The number of write I/Os per second.
ƒ The amount of data that are written per
second (KB/sec)
ƒ The initial copy hit rate (percent)
ƒ The average transfer rate (KB/sec) for initial
copy operations
ƒ The number of asynchronous remote I/Os per
second at the primary storage system
ƒ The number of journals at the primary
storage system
ƒ The average transfer rate (KB/sec) for
journals in the primary storage system
ƒ The remote I/O average response time
(milliseconds) on the primary storage system
ƒ The number of asynchronous remote I/Os per
second at the secondary storage system
ƒ The number of journals at the secondary
storage system
ƒ The average transfer rate (KB/sec) for
journals in the secondary storage system
ƒ The remote I/O average response time
(milliseconds) on the secondary storage
system
Note: 1 millisecond is one-thousandth of 1 second.
