Using the Export Tool 7-7
Hitachi Universal Storage Platform V/VM Hitachi Performance Manager User’s Guide
Table 7-5 Files with Statistics about Ports
ZIP File CSV File Data Saved in the File
Port_IOPS.csv The number of read and write operations per
second at ports
Port_KBPS.csv The size of data transferred per second at ports
(KB/sec)
Port_Response.csv The average response time (microseconds) at
ports
Port_Initiator_IOPS.csv The number of read and write operations per
second at Initiator/External ports
Port_Initiator_KBPS.csv The size of data transferred per second at
Initiator/External ports (KB/sec)
Port_dat.ZIP
Port_Initiator_Response.csv The average response time (microseconds) at
Initiator/External ports
Note: * 1 microsecond is one-millionth of 1 second.
Table 7-6 Files with Statistics about Host Bus Adapters Connected to
Ports
ZIP File CSV File Data Saved in the File
PortWWN_xx_IOPS.csv The I/O rate (that is, the number of read and
write operations per second) for HBAs that are
connected to a port
PortWWN_xx_KBPS.csv The size of data transferred per second (KB/sec)
between a port and the HBAs connected to that
port
PortWWN_dat.ZIP
PortWWN_xx_Response.csv The average response time (microseconds)
between a port and the HBAs connected to that
port
Notes :
ƒ 1 microsecond is one-millionth of 1 second.
ƒ The letters "xx" in CSV filenames indicate a port name. For example, if the filename is PortWWN_1A_IOPS.csv, the
file contains the I/O rate for each host bus adapter connected to the CL1-A port.
ƒ If files are exported to a Windows computer, CSV filenames may end with numbers (for example,
PortWWN_1A_IOPS-1.csv and PortWWN_1a_IOPS-2.csv).
