84
4-Way Stereo Compact Line-Array for mid-sized venues
4-Way Stereo + Sub Compact Line-Array for mid sized venues, higher SPL’s
Cabinets 12 XLC127+, 6 Xsub
Amplifiers 6 CP2200, 2 P3000
Controllers 2 Dx38
Cabling 6 NL8 long, 12 NL8 short, 2 XLC grids,
& Accessories 12 dollies 127 (or 2 bottom dollies), 2 Xline dollies
Horizontal Coverage 2 x 120°
Typical Distance 30 m to 50 m
Total Amp Power 2 x 7,000W = 14,000W
Options&Comments -
Cabinets 16 XLC127+, 10 XLC118, 4 Xsub
Amplifiers 12 CP3000S, 2 P3000
Controllers 3 Dx38
Cabling 6 NL8 long, 14 NL8 short, 4 XLC grids,
6 XLC bottom dollies, 1 Xline dolly
Horizontal Coverage 2 x 120°
Typical Distance 30 m to 50 m
Total Amp Power 2 x 17,000W = 34,000W
Options&Comments XLC127+ can be driven also with P1200RL
Xsub with P3000RL
