Sx 100 / Sx 300 / Sb 121
Sx 500 +
Horizontal Cluster 120° (2 systems)
Horizontal Cluster 140° (2 systems)
Vertical Cluster Wall-mount Sx-Series™ hardware-overview:
Horizontal Cluster 210° (3 systems)
2 x MB 200 + 1 x MB 300 neccessary
2 x MB 500 + 1 x MB 600 neccessary
2 x MB 500 neccessary 1 x MB 500 neccessary
3 x MB 500 + 2 x MB 600 neccessary
3 x MB 200 + 2 x MB 300 neccessary
Wall or ceiling-mount
Vertical Cluster
Horizontal Cluster 180° (3 systems)
Sx 80 Sx 80 SM Stand mount black
Sx 80 MBB U-bracket black
Sx 80 MBW U-bracket white
Sx 100+ MB 200 B U-bracket black
MB 200 W U-bracket white
Sx 300 MB 300 B Array-kit (2 plates) black
Sb 121 MB 300 W Array-kit (2 plates) white
Sx 500 + MB 500 U-bracket black
MB 600 Array-kit black
Note: Flying and suspending of speakers requires authorized personnel
1 x MB 200 neccessary
2 x MB 200
neccessary
3/8“ Quick links
neccessary
3/8“ Quick links
neccessary
3/8“ Quick links
neccessary
3/8“ Quick links
neccessary
Eyebolt nec-
cessary
Eyebolt nec-
cessary
