Mounting hardware
Note: Flying and suspending of speakers requires authorized personnel
EVI-12MBB black
EVI-12MBW white
EVI-15MBB black
EVI-15MBW white
EVI-28MBB black
EVI-28MBW white
The radius
of action is
140°.
EVI-12
Ceiling mount
EVI-15
Ceiling mount
EVI-28
Wall or ceiling mount
S-40 FRi-2082 Xi- 1082
Sx 80
Wall, ceiling or stand mount
Stand mount
Under balcony or on-wall mount Under balcony or
on-wall mount
S-40 MB/B: black
S-40 MB/W: white
Note: The threat
diameter can be
reduced with a
standard 5/8-inch
screw adapter for
different mic
stands.
Sx 80 SM black
For speakers stands
with 35 mm diameter.
Wall or ceiling mount Sx 250/SxA250
Sk-1 Rigging Kit
Sx 80 MBB black
Sx 80 MBW white
For cost effective
installation.
MB-1082: black
The 100° x 100° dispersion angle allows
one to install FRi-2082 vertically on the
wall as well. Mounting bracket comes with
FRi-2082.
on-wall
100° 90°
SAM™ comes with each
EVID™ system and includes
a hex-key-tool. SAM™ has
angle markers to make
installation easier.
EVID 3.2 / 4.2 / 6.2 Angle markers EVID 12.1
Bracket passes EIA 636 at a
safety factor of 8:1.
The bracket for on-wall or
corner mounting and a safety
eyebolt comes with EVID
12.1.
