Compact Precision Amplifiers
• Four models ranging from 2 x 600 W
to 2 x 1600 W
• EV’s legendary Precision Series sound
• 30% dynamic headroom
• Class-H design for less heat dissipation
• Very light and compact format
• High-precision detent front controls
• Dynamic audio limiter
• Robust construction & reliable design
• Unique protection package including
Back-EMF protection
The flagship of the Precision Series Compact amplifiers is not only
the first Precision Series amplifier to use a switch-mode power
supply, but also the first switch-mode amplifier with EV’s Preci-
sion Series sound. With up to 2 x 1600 watts into 2 Ohms and 2
x 1100 watts into 4 Ohms, it is not only the most powerful in the
line, but also the lightest model at only 17.96 lbs (8.15 kg).
The CP 3000 S is state-of-the-art for all applications. It’s specifi-
cally designed to allow for long-term driving of low loads with
subwoofers without stress. Its reliability coupled with its pleasing,
rich sound makes it the first choice for all mid- and hi- speaker
cabinets.
CP3000S CP2200 CP1800 CP1200
Maximum power (1k Hz; THD <1%)
2 ohms
1600 W 1100 W 900 W 600 W
4 ohms 1100 W 800 W 600 W 400 W
8 ohms 600 W 500 W 350 W 240 W
Rated power (20 Hz–20 kHz; THD <0.2%)
4 ohms
900 W 700 W 500 W 300 W
8 ohms 450 W 350 W 250 W 150 W
Maximum bridged output (1,000 Hz; <1% THD)
4 ohms
3200 W 2200 W 1800 W 1200 W
8 ohms 2200 W 1600 W 1200 W 800 W
Slew rate 35 V/µs 35 V/µs 30 V/µs 25 V/µs
Total harmonic distortion <0.05% <0.05% <0.05% <0.05%
Intermodulation distortion (SMPTE) <0.02% <0.02% <0.02% <0.02%
Crosstalk (at 1,000 Hz) <-80 dB <-80 dB <-80 dB <-80 dB
Input impedance (balanced) 20 k Ω 20 k Ω 20 k Ω 20 k Ω
Signal-to-noise ratio (dB A-weighted) 107 dB 107 dB 105,5 dB 103,5 dB
Dimensions (W x H x D) 483 x 88.1 x 368.8 mm 483 x 88.1 x 368.8 mm 483 x 88.1 x 368.8 mm 483 x 88.1 x 368.8 mm
19" x 3.5" x 15.22" 19" x 3.5" x 15.22" 19" x 3.5" x 15.22" 19" x 3.5" x 15.22"
Net weight 8.15 kg (17.96 lbs.) 16 kg (35.2 lbs.) 15 kg (33 lbs.) 13.5 kg (30.8 lbs.)
CP3000 S
With up to 2 x 1100 watts into 2 Ohms and 2 x 800
watts into 4 Ohms, the CP 2200 is not only a perfect
complement to many fullrange speaker cabinets, but also
mid- and hi-frequency components in larger concert-sound
systems. The CP 2200 employs a conventional trans-
former power supply.
CP2200
Supplies up to 2 x 900 watts into 2 Ohms and 2 x 600 watts
into 4 Ohms. Dedicated for smaller size full range speaker
systems and hi-frequency components in multiway systems.
The CP 1800 uses a conventional transformer power supply.
CP1800
With up to 2 x 600 watts into 2 Ohms and 2 x 400 watts into
4 Ohms dedicated for small fullrange cabinets and individual
hi-frequency components in multiway systems. The CP1200
employs a conventional transformer power supply.
CP1200
