Electro-Voice Microphone - Manual (Page 71)

71
PolarChoice TM Desktop & PolarChoice TM Satellite
PolarChoice Desktop and Satellite microphones add mobility & flexibility
to PolarChoice’s excellent sound qualities :
The PolarChoice Desktop is a free-standing podium style
microphone, firmly anchored in place by its elegantly
designed base. Select one of four polar patterns (omni, car-
dioid, super-cardiod or hyper-cardioid), via the easy to
access switch. All patterns feature identical voicing, eliminat-
ing the need to retune the sound system. The PC-Desktop
can also be interfaced to an auto-mixer for use in those large
and difficult, multiple microphone installations.
The free standing and movable PolarChoice Desktop can be
used anywhere a gooseneck or podium style mic is needed,
but a permanent installation is not possible, required or
desired. Whether it’s a boardroom conference table, video-
conference facility, training room, house-of-worship altar, or
even on a podium - with the PolarChoice Desktop, anything is
possible.
PolarChoice Desktop PolarChoice Satellite
Element type Back electret condenser Back electret condenser
Selectable Polar Patterns Omni,Cardioid,Supercardioid,Hypercardioid Omni,Cardioid,Supercardioid,Hypercardioid
Impedance 200 Ohms 200 Ohms
Frequency Response 50 Hz - 20 kHz(mic system) 50 Hz - 20 kHz(mic system)
Open Circuit Voltage 5,6 mV/Pascal 5,6 mV/Pascal(mic system)
Equivalent Noise < 26 dB SPL(A-weighted) < 26 dB SPL(A-weighted, mic system)
Max. SPL >135 dB >135 dB(mic system)
Power requirement 24 to 52 Volt Phantom Power 5 V DC from Beltpack
Current Consumption 3 mA 3 mA
Finish Nonreflective Black Nonreflective Black
Included Accessories Multiport Windscreen Multiport Windscreen
Connector Type 3-pin XLR TA4F
Dimensions 45 x 114 x 178 mm(HWD) excl.gooseneck 45 x 114 x 178 mm(HWD) excl.gooseneck
1.77” x 4.49” x 7.01”(HWD) excl.gooseneck 1.77” x 4.49” x 7.01”(HWD) excl.gooseneck
Weight 690 g (1.52 lbs.) 690 g (1.52 lbs.) + beltpack
PolarChoice Desktop
The PolarChoice satellite brings the benefits of wireless to
the boardroom, conference center, or podium. The Polar-
Choice Satellite is a free-standing gooseneck-style micro-
phone, firmly anchored in place by its elegantly designed
base. This low-profile foundation hides PolarChoice Satel-
lite’s most powerful feature: space for a wireless transmit-
ter. Turn the base over to reveal the specially designed
compartment for housing a Telex or Electro-Voice body-
pack transmitter. Connect the microphone to the bodypack,
set up the wireless channel, and place PC Satellite any-
where an easy-to-use microphone is required. No longer
do you have to cut holes in tables, run long cables, or com-
promise the architectural integrity of an installation. With
the PolarChoice Satellite, anything is possible.
PolarChoice Satellite
THE WORLDS FIRST THE WORLDS FIRST
WIRELESS PODIUM WIRELESS PODIUM
MICROPHONE! MICROPHONE!
PolarChoice Desktop PolarChoice Satellite
